Individual hose record

4666677 Hose Repair Specifications

Excavator · Hitachi · ZX225US-3 · Boom Assembly

Finished length910 mm

Locate this hose

Installation diagram — Pipe No. 25A

Locate Pipe No. 25A in the diagram, then confirm part number 4666677 before removing the hose.

Hitachi ZX225US-3 installation diagram showing hydraulic hose 4666677 at Pipe No. 25A — **Hitachi ZX225US-3**Part 4666677 · Pipe No. 25AOpen full-size diagram

Repair specifications

Part number: 4666677
Diagram pipe number: 25A
Installation route: Boom cylinder — left 2 / left 3Original Chinese: 大臂油缸左2/左3
Hose specification: DN16;4SP-10;34.5Mpa
Finished length: 910 mm
Working pressure: 34.5 MPa
Left fitting: American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
Right fitting: American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
Quantity: 1

Same system

Related Hoses

Diagram Pipe No. 7

4628514

Installation route: Arm cylinder — leftOriginal Chinese: 小臂油缸左

Length: 900 mm
Specification: DN19;4SH-12;42MPa
Left fitting: American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
Right fitting: American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封

View full repair specifications

Diagram Pipe No. 6

4628956

Installation route: Arm cylinder — rightOriginal Chinese: 小臂油缸右

Length: 900 mm
Specification: DN25;4SH-16;38.8MPa
Left fitting: American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
Right fitting: American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封

View full repair specifications
