Individual hose record
DS2094006 Hose Repair Specifications
Excavator · Doosan · DX160LC · Control Lever
Finished length400 mm
Locate this hose
Installation diagram — Pipe No. 10
Locate Pipe No. 10 in the diagram, then confirm part number DS2094006 before removing the hose.
Repair specifications
- Part number
- DS2094006
- Diagram pipe number
- 10
- Installation route
- Left control lever port T → return valveOriginal Chinese: 左手柄T口~回油阀
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 400 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
