Individual hose record
2184-1026D32 Hose Preview
Excavator · Doosan · DX140LCR · Attachments
Finished length1,100 mm
Repair specifications
- Part number
- 2184-1026D32
- Diagram pipe number
- 14
- Installation route
- Control valve → return steel line (hydraulic tank)Original Chinese: 控制阀~回油铁管(液压油箱)
- Hose specification
- DN13;1SN-08;16MPa
- Finished length
- 1,100 mm
- Working pressure
- 16 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
Manual diagrams
Installation and Exploded Views
A red marker identifies a reviewed hose location.
For reference only. Confirm the actual hose before fabrication.
