Individual hose record
4437282 Hose Repair Specifications
Excavator · Hitachi · ZX160LC · Control Lever
Finished length550 mm
Locate this hose
Installation diagram — Pipe No. 39A
Locate Pipe No. 39A in the diagram, then confirm part number 4437282 before removing the hose.
Repair specifications
- Part number
- 4437282
- Diagram pipe number
- 39A
- Installation route
- 中转接头~分配阀下
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 550 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
