- Length
- 940 mm
- Specification
- DN10;-6;10.3Mpa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
Individual hose record
113-6726 Hose Repair Specifications
Excavator · Caterpillar · CAT®316F · Solenoid Valve
Finished length720 mm
Locate this hose
Installation diagram — Pipe No. 4
Locate Pipe No. 4 in the diagram, then confirm part number 113-6726 before removing the hose.
Repair specifications
- Part number
- 113-6726
- Diagram pipe number
- 4
- Installation route
- 电磁阀(分配阀前)~控制阀(回转接头右)
- Hose specification
- DN10;1SN-6;10.4Mpa
- Finished length
- 720 mm
- Working pressure
- 10.4 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 1
Same system
Related Hoses
For reference only. Confirm the actual hose before fabrication.
