Individual hose record
2184-1045D196 Hose Preview
Excavator · Doosan · DX140LCR · Grease Lines
Finished length1,730 mm
Repair specifications
- Part number
- 2184-1045D196
- Diagram pipe number
- 6
- Installation route
- Two-piece boom grease lineOriginal Chinese: 分节大臂黄油管
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 1,730 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
Manual diagrams
Installation and Exploded Views
A red marker identifies a reviewed hose location.
For reference only. Confirm the actual hose before fabrication.
