Individual hose record
2184-1046D219 Hose Preview
Excavator · Doosan · DX140LCR · Attachments – Lock Valve
Finished length2,100 mm
Repair specifications
- Part number
- 2184-1046D219
- Diagram pipe number
- 12
- Installation route
- Two-piece boom cylinder lock valve → connector plate (two-piece boom cylinder lock valve)Original Chinese: 分节油缸锁止阀~接线板(分节油缸锁止阀)
- Hose specification
- DN6;2SN-04;40MPa
- Finished length
- 2,100 mm
- Working pressure
- 40 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 2
Manual diagrams
Installation and Exploded Views
A red marker identifies a reviewed hose location.
For reference only. Confirm the actual hose before fabrication.
