Individual hose record
4229841 Hose Repair Specifications
Excavator · Hitachi · EX200LC-2 · Boom Assembly
Finished length1,600 mm
Locate this hose
Installation diagram — Pipe No. 1
Locate Pipe No. 1 in the diagram, then confirm part number 4229841 before removing the hose.
Repair specifications
- Part number
- 4229841
- Diagram pipe number
- 1
- Installation route
- Bucket cylinderOriginal Chinese: 铲斗油缸
- Hose specification
- DN19;4SP-12;34.5MPa
- Finished length
- 1,600 mm
- Working pressure
- 34.5 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 2
