Individual hose record
DS2093138 Hose Preview
Excavator · Doosan · DX140LCR · Control Lever
Finished length770 mm
Repair specifications
- Part number
- DS2093138
- Diagram pipe number
- 2
- Installation route
- Intermediate adapter → pattern-change valve ports A2/C2Original Chinese: 中转接头~模式转换阀A2/C2口
- Hose specification
- DN10;1SN-06;18MPa
- Finished length
- 770 mm
- Working pressure
- 18 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 2
Manual diagrams
Installation and Exploded Views
A red marker identifies a reviewed hose location.
For reference only. Confirm the actual hose before fabrication.
