Individual hose record
DS2094001 Hose Preview
Excavator · Doosan · DX140LCR · Control Lever
Finished length720 mm
Repair specifications
- Part number
- DS2094001
- Diagram pipe number
- 162
- Installation route
- Intermediate adapter → control valveOriginal Chinese: 中转接头~分配阀
- Hose specification
- DN10;1SN-06;18MPa
- Finished length
- 720 mm
- Working pressure
- 18 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
Manual diagrams
Installation and Exploded Views
A red marker identifies a reviewed hose location.
For reference only. Confirm the actual hose before fabrication.
