Individual hose record

4471875 Hose Repair Specifications

Excavator · Hitachi · ZX75US · Control Lever

Finished length1,480 mm

Locate this hose

Installation diagram — Pipe No. 2

Locate Pipe No. 2 in the diagram, then confirm part number 4471875 before removing the hose.

Hitachi ZX75US installation diagram showing hydraulic hose 4471875 at Pipe No. 2 — Hitachi ZX75USPart 4471875 · Pipe No. 2Open full-size diagram

Repair specifications

Part number: 4471875
Diagram pipe number: 2
Installation route: 左手柄~接线板(手柄)
Hose specification: DN6;1SN-4;7Mpa
Finished length: 1,480 mm
Working pressure: 7 MPa
Left fitting: 美制内螺纹37°内锥
Right fitting: 美制内螺纹37°内锥
Quantity: 1

Same system

Related Hoses

Diagram Pipe No. 4

4471887

Installation route: 右手柄~进回油阀

Length: 2,150 mm
Specification: DN6;1SN-4;7Mpa
Left fitting: 美制内螺纹37°内锥
Right fitting: 美制内螺纹37°内锥

View full repair specifications

For reference only. Confirm the actual hose before fabrication.
