Individual hose record
8V-8646 Hose Repair Specifications
Excavator · Caterpillar · CAT®231D · Swivel Joint
Finished length1,395 mm
Locate this hose
Installation diagram — Pipe No. 11
Locate Pipe No. 11 in the diagram, then confirm part number 8V-8646 before removing the hose.
Repair specifications
- Part number
- 8V-8646
- Diagram pipe number
- 11
- Installation route
- 回转接头~行走马达(规格3)
- Hose specification
- DN19;1SN-12;8.7Mpa
- Finished length
- 1,395 mm
- Working pressure
- 8.7 MPa
- Left fitting
- 美制内螺纹37°锥
- Right fitting
- 美制内螺纹37°锥
- Quantity
- 2
For reference only. Confirm the actual hose before fabrication.
