Individual hose record

5W-4894 Hose Repair Specifications

Excavator · Caterpillar · CAT®212 · Hydraulic Tank

Finished length250 mm

Locate this hose

Installation diagram — Pipe No. 1

Locate Pipe No. 1 in the diagram, then confirm part number 5W-4894 before removing the hose.

Caterpillar CAT®212 installation diagram showing hydraulic hose 5W-4894 at Pipe No. 1 — Caterpillar CAT®212Part 5W-4894 · Pipe No. 1Open full-size diagram

Repair specifications

Part number: 5W-4894
Diagram pipe number: 1
Installation route: 液压油箱~回油铁管
Hose specification: DN25;1SN-16;7Mpa
Finished length: 250 mm
Working pressure: 7 MPa
Left fitting: 公制内螺纹24°锥带O形圈-轻型
Right fitting: 公制外螺纹24°锥-轻型
Quantity: 1

For reference only. Confirm the actual hose before fabrication.
