Individual hose record
DS2093300 Hose Preview
Excavator · Doosan · DX140LCR · Control Valve
Finished length420 mm
Repair specifications
- Part number
- DS2093300
- Diagram pipe number
- 29
- Installation route
- Control valve port PA4 → control valve port PA8Original Chinese: 分配阀PA4口~分配阀PA8口
- Hose specification
- -
- Finished length
- 420 mm
- Left fitting
- Female threadOriginal Chinese: 内螺纹
- Right fitting
- 90° elbow, female threadOriginal Chinese: 90°内螺纹
- Quantity
- 1
Manual diagrams
Installation and Exploded Views
A red marker identifies a reviewed hose location.
For reference only. Confirm the actual hose before fabrication.
