Individual hose record
104-8973 Hose Repair Specifications
Excavator · Caterpillar · CAT®312D2 · Swing Motor
Finished length1,700 mm
Locate this hose
Installation diagram — Pipe No. 17
Locate Pipe No. 17 in the diagram, then confirm part number 104-8973 before removing the hose.
Repair specifications
- Part number
- 104-8973
- Diagram pipe number
- 17
- Installation route
- 回转马达~蓄能器电磁阀(液压泵旁左)
- Hose specification
- DN10;1SN-6;10.4Mpa
- Finished length
- 1,700 mm
- Working pressure
- 10.4 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 1
For reference only. Confirm the actual hose before fabrication.
