Individual hose record
DS2094048 Hose Preview
Excavator · Doosan · DX140LCR · Attachments – Breaker
Finished length360 mm
Repair specifications
- Part number
- DS2094048
- Diagram pipe number
- 11
- Installation route
- Breaker pedal port T → return valveOriginal Chinese: 破碎器踏板T口~回油阀
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 360 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
Manual diagrams
Installation and Exploded Views
A red marker identifies a reviewed hose location.
For reference only. Confirm the actual hose before fabrication.
