Individual hose record
5I-3127 Hose Repair Specifications
Excavator · Caterpillar · CAT®317 N · Control Lever
Finished length1,900 mm
Locate this hose
Installation diagram — Pipe No. 56
Locate Pipe No. 56 in the diagram, then confirm part number 5I-3127 before removing the hose.
Repair specifications
- Part number
- 5I-3127
- Diagram pipe number
- 56
- Installation route
- Intermediate adapter → control valveOriginal Chinese: 中转接头~分配阀
- Hose specification
- DN10;-6;10.3Mpa
- Finished length
- 1,900 mm
- Working pressure
- 10.3 MPa
- Left fitting
- 美制内螺纹37°锥
- Right fitting
- 美制内螺纹37°锥
- Quantity
- 3
