Individual hose record

4454670 Hose Repair Specifications

Excavator · Hitachi · EX1200-7 · Boom Assembly

Finished length2,700 mm

Locate this hose

Installation diagram — Pipe No. 21

Locate Pipe No. 21 in the diagram, then confirm part number 4454670 before removing the hose.

Hitachi EX1200-7 installation diagram showing hydraulic hose 4454670 at Pipe No. 21
Hitachi EX1200-7Part 4454670 · Pipe No. 21Open full-size diagram

Repair specifications

Part number
4454670
Diagram pipe number
21
Installation route
Bucket cylinderOriginal Chinese: 铲斗油缸
Hose specification
DN32;6SP-20;34.5MPa
Finished length
2,700 mm
Working pressure
34.5 MPa
Left fitting
Heavy-series flangeOriginal Chinese: 法兰-重型
Right fitting
Heavy-series flangeOriginal Chinese: 法兰-重型
Quantity
2

Same system

Related Hoses

Diagram Pipe No. 27

4347824

Installation route: Bucket cylinderOriginal Chinese: 铲斗油缸

Length
2,700 mm
Specification
DN38;6SP-24;34.5MPa
Left fitting
Heavy-series flangeOriginal Chinese: 法兰-重型
Right fitting
Heavy-series flangeOriginal Chinese: 法兰-重型
View full repair specifications

Diagram Pipe No. 8

4454680

Installation route: 小臂(背部)~过渡阀块(装载斗)

Length
2,015 mm
Specification
DN32;6SP-20;34.5MPa
Left fitting
Heavy-series flangeOriginal Chinese: 法兰-重型
Right fitting
Heavy-series flangeOriginal Chinese: 法兰-重型
View full repair specifications
