Individual hose record
4632449 Hose Repair Specifications
Excavator · Hitachi · ZX225USLC-3 · Swivel Joint
Finished length2,200 mm
Locate this hose
Installation diagram — Pipe No. 0
Locate Pipe No. 0 in the diagram, then confirm part number 4632449 before removing the hose.
Repair specifications
- Part number
- 4632449
- Diagram pipe number
- 0
- Installation route
- Swivel joint → travel motorOriginal Chinese: 回转接头~行走马达
- Hose specification
- DN19;4SH-12;42MPa
- Finished length
- 2,200 mm
- Working pressure
- 42 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- 90° elbow, American female thread, flat-face sealOriginal Chinese: 90°美制内螺纹平面密封
- Quantity
- 2
