Individual hose record
DS2093013 Hose Preview
Excavator · Doosan · DX140LCR · Attachments
Finished length460 mm
Repair specifications
- Part number
- DS2093013
- Diagram pipe number
- 62
- Installation route
- Attachment pedal port 2 → solenoid valve (attachment)Original Chinese: 附加装置踏板2口~电磁阀(附加装置)
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 460 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 1
Manual diagrams
Installation and Exploded Views
A red marker identifies a reviewed hose location.
For reference only. Confirm the actual hose before fabrication.
