Individual hose record

4651937 Hose Repair Specifications

Excavator · Hitachi · ZX270LC · Attachments – Lock Valve

Finished length6,100 mm

Locate this hose

Installation diagram — Pipe No. 33A

Locate Pipe No. 33A in the diagram, then confirm part number 4651937 before removing the hose.

Hitachi ZX270LC installation diagram showing hydraulic hose 4651937 at Pipe No. 33A — Hitachi ZX270LCPart 4651937 · Pipe No. 33AOpen full-size diagram

Repair specifications

Part number: 4651937
Diagram pipe number: 33A
Installation route: 小臂油缸锁止阀~接线板(锁止阀)
Hose specification: DN10;1SN-6;7Mpa
Finished length: 6,100 mm
Working pressure: 7 MPa
Left fitting: 美制内螺纹37°内锥
Right fitting: 美制内螺纹37°内锥
Quantity: 2

Same system

Related Hoses

Diagram Pipe No. 14A

4618388

Installation route: 小臂油缸锁止阀~液压油箱

Length: 4,550 mm
Specification: DN10;1SN-6;7Mpa
Left fitting: 美制内螺纹37°内锥
Right fitting: 美制内螺纹37°内锥

View full repair specifications

For reference only. Confirm the actual hose before fabrication.
