Caterpillar 349D2 Hydraulic Hose Length & Fitting Lookup
Available Caterpillar 349D2 workshop notes include part numbers and recorded lengths for hose lookup. Verify every value and both fittings on the machine before fabrication.
Fast lookup
Find the exact hose data you need
Search the complete catalog by model, brand, part number, system, hose specification, or installation route.
A model or part number usually gives the fastest result.
Digitized data and source sheets
Caterpillar 349D2 Hose Data and Original Handwritten Sheets
The table is a searchable transcription of the Caterpillar 349D2 workshop notes. The complete original handwritten sheets are shown below without cropping.
Digitized measurements from these sheets
| Part number | Recorded length |
|---|---|
| 4I-0821 | 650 mm |
| 4I-1104 | 330 mm |
| 4I-1780 | 1,450 mm |
| 4I-3511 | 3,350 mm |
| 4I-3513 | 2,000 mm |
| 4I-6003 | 2,650 mm |
| 7Y-4173 | 2,800 mm |
| 087-578213IL1316 | 550 mm |
| 236-2844OI160 | 1,200 mm |
| 330-231825I1716AF0 | 900 mm |
| I11-6752 | 12,200 mm |
| T314-8082 | 1,575 mm |
Original handwritten sheets
Complete pages are shown in their original proportions without cropping.
