Volvo EC360B LC Workshop Hose Notes

Workshop notebook pages related to the Volvo EC360B LC may help identify the machine or hose. Confirm all manufacturing specifications on the machine.

Fast lookup

Find the exact hose data you need

Search the complete catalog by model, brand, part number, system, hose specification, or installation route.

A model or part number usually gives the fastest result.

Technician notes

Workshop measurements

These notebook pages may help identify a hose or compare a recorded length. Confirm the final length, fittings, pressure rating, and routing on the machine before fabrication.

Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 8 of 10
Notebook page 8 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 6 of 10
Notebook page 6 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 2 of 10
Notebook page 2 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 5 of 10
Notebook page 5 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 1 of 10
Notebook page 1 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 9 of 10
Notebook page 9 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 4 of 10
Notebook page 4 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 7 of 10
Notebook page 7 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 3 of 10
Notebook page 3 of 10View full-size
Volvo EC360B LC hydraulic hose part numbers and recorded lengths — technician notebook page 10 of 10
Notebook page 10 of 10View full-size
Workshop measurements
Part numberRecorded length
3L11VOE148821391,125 mm
5A9451-03231,550 mm
7VOE148812571,015 mm
SA945-022291,450 mm
SA945-022296I1,450 mm
SA945-032351,650 mm
SA945-032804,000 mm
SA945-052003,300 mm
SA9451-022091,450 mm
SA9451-022341,700 mm
SA9451-02242,050 mm
SA9451-02252,950 mm
SA9451-032133,650 mm
SA9451-0323Z1,600 mm
SA9451-032311,550 mm
SA9451-032321,600 mm
SA9451-032341,700 mm
SA9451-032381,900 mm
SA9451-032613,050 mm
SA9451-032653,250 mm
SA9451-0327Z3,600 mm
SA9451-032733,650 mm
SA9451-032814,000 mm
SA9451-0439313I4,650 mm
SA9451-0526013,300 mm
SA9452-03251,250 mm
SA9453-02209450 mm
SA9453-0221550 mm
SA9453-0221Y700 mm
SA9453-02210500 mm
SA9453-02211550 mm
SA9453-022186I900 mm
SA9453-02221,300 mm
SA9453-022311,550 mm
SA9453-022341,700 mm
SA9453-023412,350 mm
SA9453-03212600 mm
SA9453-03218900 mm
SA9453-0322600 mm
SA9453-032221,100 mm
SA9453-032241,200 mm
SA9453-043201,000 mm
SA9453-043211,050 mm
SA9453-04501450 mm
SA9453-04509450 mm
SA9453-0535719I2,900 mm
SA9453-062301,500 mm
SA9453-072331,650 mm
SA9497-07652,800 mm
SA9751-032261,300 mm
SA9753-043211,050 mm
SH945-032301,500 mm
VOE148800T4670 mm
VOE9362711,250 mm
VOE9362771,250 mm
VOE9369851,250 mm
VOE9373504,000 mm
VOE9375842,900 mm
VOE9376182,850 mm
VOE937751450 mm
VOE14880751,580 mm
VOE14881251,015 mm
VOE14602345690 mm
VOE14880543650 mm
VOE148807471,430 mm
VOE148807481,480 mm
VOE148808501,070 mm
VOE148819541,175 mm
VOE17602326870 mm
VOEIII28651,560 mm
