Individual hose record

8K-4863 Hose Repair Specifications

Excavator · Caterpillar · CAT®245 · Hydraulic Pump

Finished length558 mm

Locate this hose

Installation diagram — Pipe No. 7

Locate Pipe No. 7 in the diagram, then confirm part number 8K-4863 before removing the hose.

Caterpillar CAT®245 installation diagram showing hydraulic hose 8K-4863 at Pipe No. 7 — Caterpillar CAT®245Part 8K-4863 · Pipe No. 7Open full-size diagram

Repair specifications

Part number: 8K-4863
Diagram pipe number: 7
Installation route: 液压泵~液压油箱
Hose specification: DN25;1SN-16;7Mpa
Finished length: 558 mm
Working pressure: 7 MPa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥
Quantity: 1

Same system

Related Hoses

Diagram Pipe No. 31

4V-9199

Installation route: 液压泵~液压油箱

Length: 585 mm
Specification: DN25;1SN-16;7Mpa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥

View full repair specifications

For reference only. Confirm the actual hose before fabrication.
