Individual hose record

8K-0800 Hose Repair Specifications

Excavator · Caterpillar · CAT®225 · Attachments

Finished length894 mm

Locate this hose

Installation diagram — Pipe No. 4

Locate Pipe No. 4 in the diagram, then confirm part number 8K-0800 before removing the hose.

Caterpillar CAT®225 installation diagram showing hydraulic hose 8K-0800 at Pipe No. 4 — Caterpillar CAT®225Part 8K-0800 · Pipe No. 4Open full-size diagram

Repair specifications

Part number: 8K-0800
Diagram pipe number: 4
Installation route: 铲斗油缸~先导阀
Hose specification: DN13;1SN-8;14Mpa
Finished length: 894 mm
Working pressure: 14 MPa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥
Quantity: 1

Same system

Related Hoses

Diagram Pipe No. 18

8K-4809

Installation route: 行走马达~壳体排放过滤器

Length: 1,375 mm
Specification: DN19;1SN-12;8.7Mpa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥

View full repair specifications

For reference only. Confirm the actual hose before fabrication.
