Individual hose record
4449272 Hose Repair Specifications
Excavator · Hitachi · ZX180W · Solenoid Valve
Finished length2,100 mm
Locate this hose
Installation diagram — Pipe No. 10A
Locate Pipe No. 10A in the diagram, then confirm part number 4449272 before removing the hose.
Repair specifications
- Part number
- 4449272
- Diagram pipe number
- 10A
- Installation route
- 电磁阀(隔板)~蓄能器
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 2,100 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
