Individual hose record
5C-4391 Hose Repair Specifications
Excavator · Caterpillar · CAT®219 · Attachments
Finished length670 mm
Locate this hose
Installation diagram — Pipe No. 14
Locate Pipe No. 14 in the diagram, then confirm part number 5C-4391 before removing the hose.
Repair specifications
- Part number
- 5C-4391
- Diagram pipe number
- 14
- Installation route
- 溢流阀(大臂)~履带制动阀
- Hose specification
- DN10;4SP-6;28Mpa
- Finished length
- 670 mm
- Working pressure
- 28 MPa
- Left fitting
- 美制内螺纹37°锥
- Right fitting
- 美制内螺纹37°锥
- Quantity
- 1
