Individual hose record

033-2159 Hose Repair Specifications

Excavator · Caterpillar · CAT®235 · Attachments

Finished length368 mm

Locate this hose

Installation diagram — Pipe No. 18

Locate Pipe No. 18 in the diagram, then confirm part number 033-2159 before removing the hose.

Caterpillar CAT®235 installation diagram showing hydraulic hose 033-2159 at Pipe No. 18 — Caterpillar CAT®235Part 033-2159 · Pipe No. 18Open full-size diagram

Repair specifications

Part number: 033-2159
Diagram pipe number: 18
Installation route: 单向阀(增压器)~控制阀(增压器)
Hose specification: DN13;1SN-8;14Mpa
Finished length: 368 mm
Working pressure: 14 MPa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥
Quantity: 1

Same system

Related Hoses

Diagram Pipe No. 3

8K-4232

Installation route: 液压油散热器左~液压油散热器右

Length: 950 mm
Specification: DN25;1SN-16;7Mpa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥

View full repair specifications

Diagram Pipe No. 6

2V-8679

Installation route: 接线板(驾驶室后)~

Length: 794 mm
Specification: DN10;1SN-6;15.7Mpa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥

View full repair specifications

For reference only. Confirm the actual hose before fabrication.
