Individual hose record

2V-8679 Hose Repair Specifications

Excavator · Caterpillar · CAT®235 · Attachments

Finished length794 mm

Locate this hose

Installation diagram — Pipe No. 6

Locate Pipe No. 6 in the diagram, then confirm part number 2V-8679 before removing the hose.

Caterpillar CAT®235 installation diagram showing hydraulic hose 2V-8679 at Pipe No. 6 — Caterpillar CAT®235Part 2V-8679 · Pipe No. 6Open full-size diagram

Repair specifications

Part number: 2V-8679
Diagram pipe number: 6
Installation route: 接线板(驾驶室后)~
Hose specification: DN10;1SN-6;15.7Mpa
Finished length: 794 mm
Working pressure: 15.7 MPa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥
Quantity: 1

Same system

Related Hoses

Diagram Pipe No. 18

033-2159

Installation route: 单向阀(增压器)~控制阀(增压器)

Length: 368 mm
Specification: DN13;1SN-8;14Mpa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥

View full repair specifications

Diagram Pipe No. 3

8K-4232

Installation route: 液压油散热器左~液压油散热器右

Length: 950 mm
Specification: DN25;1SN-16;7Mpa
Left fitting: 美制内螺纹37°锥
Right fitting: 美制内螺纹37°锥

View full repair specifications

For reference only. Confirm the actual hose before fabrication.
