Individual hose record
8U-5383 Hose Repair Specifications
Excavator · Caterpillar · CAT®205B · Attachments
Finished length985 mm
Locate this hose
Installation diagram — Pipe No. 15
Locate Pipe No. 15 in the diagram, then confirm part number 8U-5383 before removing the hose.
Repair specifications
- Part number
- 8U-5383
- Diagram pipe number
- 15
- Installation route
- 过渡阀块(回转接头前)~阀块(右大臂油缸右)
- Hose specification
- DN6;2SN-4;40Mpa
- Finished length
- 985 mm
- Working pressure
- 40 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 1
