Individual hose record
184-9156 Hose Repair Specifications
Excavator · Caterpillar · CAT®311F LRR · Attachments – Lock Valve
Finished length1,830 mm
Locate this hose
Installation diagram — Pipe No. 2
Locate Pipe No. 2 in the diagram, then confirm part number 184-9156 before removing the hose.
Repair specifications
- Part number
- 184-9156
- Diagram pipe number
- 2
- Installation route
- 小臂油缸锁止阀
- Hose specification
- DN10;1SN-6;10.4Mpa
- Finished length
- 1,830 mm
- Working pressure
- 10.4 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 2
