Individual hose record
4I-1455 Hose Repair Specifications
Excavator · Caterpillar · CAT®315-A · Attachments
Finished length2,330 mm
Locate this hose
Installation diagram — Pipe No. 5
Locate Pipe No. 5 in the diagram, then confirm part number 4I-1455 before removing the hose.
Repair specifications
- Part number
- 4I-1455
- Diagram pipe number
- 5
- Installation route
- 踏板(附加装置)~分配阀下
- Hose specification
- DN10;-6;10.3Mpa
- Finished length
- 2,330 mm
- Working pressure
- 10.3 MPa
- Left fitting
- 美制内螺纹37°锥
- Right fitting
- 美制内螺纹37°锥
- Quantity
- 1
